FREQUENTLY ASKED QUESTIONS (faq)

For ease of use, our FAQs are divided into categories. This page is updated regularly, so please check back to learn more.

If you have a question about our products or services that is not listed here, please email: sales@metcase.co.uk with your question and our team will get back to you as soon as possible.

DESIGN-IN HELP:


DESIGN-IN HELP:

HOW DO I DOWNLOAD A METCASE DRAWING OR 3D MODEL?

Download METCASE drawings

Drawings are available for all METCASE products. This is how to download them:

1). Go to the individual product page of the part number you need (e.g. M6219145).
2). Open the 'DRAWINGS/INFO' tab at the bottom of the page. Here you can download the files.

NOTES:
- For 2D drawing files (.dwg/.pdf) you do not need to register, you can download them straightaway (.dxf files can be supplied on request).
- For 3D models (.stp/.x_t/.sat) you need to register and then login before you can download these files.
Register and login here >>


Where can I download METCASE brochures, assembly instructions and certifications?

Downloads available:

  • brochures and publications
  • assembly instructions
  • certifications such as ISO 9001:2015, REACH, RoHS.

Download these from our technical downloads page here >>
