M5504116

UNICASE 4

Attractive and highly versatile aluminium enclosure for desktop or portable electronics. Total access design with removable top and base for easier equipping. Internal PCB chassis has four guide rail positions for the PCBs. Two anodised aluminium front/rear panels included, plus 4 non-slip rubber feet. Simple assembly in just a few minutes.

Supply

Top cover, base cover, assembly extrusions (x2), front/rear panel (x2), non-slip grey rubber foot (x4), M3 x 6 mm (x16), M3 slide-in nut (x8).

2D PDF Drawing
3D/2D download

Generate Your PDF Datasheet for M5504116

Please select the product details you would like to include in the PDF.

Add to my basket Add to my basket Add to my basket
product added to your basket
continue or open your product basket
Material

Colour
Traffic white RAL 9016
Standards
REACH compliant
RoHS compliant
Width
261 mm
Depth
300 mm
Height
134.5 mm
PCB length, base
279 mm
PCB width, base
242 mm

Catalogue Pages

Assembly Instructions (Group)

Drawings

3D Models

Weight/1 part
2 kg
Customs tariff number
(METCASE product)
76169990
Country of manufacture
UK
