M5504110 UNICASE 4

M5504110

UNICASE 4

Attractive and highly versatile aluminium enclosure for desktop or portable electronics. Total access design with removable top and base for easier equipping. Internal PCB chassis has four guide rail positions for the PCBs. Two anodised aluminium front/rear panels included, plus 4 non-slip rubber feet. Simple assembly in just a few minutes.

Supply

Top cover, base cover, assembly extrusions (x2), front/rear panel (x2), non-slip grey rubber foot (x4), M3 x 6 mm (x16), M3 slide-in nut (x8).

  • Technical Data
  • Drawings / Info
  • Purchasing Data
Material
Colour
Light grey RAL 7035
Standards
REACH compliant
RoHS compliant
Width
261 mm
Depth
300 mm
Height
134.5 mm
PCB length, base
279 mm
PCB width, base
242 mm

Catalogue Pages

Assembly Instructions (Group)

Drawings (Discrepancies depend on material-specific manufacturing tolerances, e.g. DIN EN 16742)

3D-Models (Discrepancies depend on material-specific manufacturing tolerances, e.g. DIN EN 16742)

Weight/1 part
2 kg
Customs tariff number
(METCASE product)
76169990
Country of manufacture
U.K.
